Setup

Device Management

Anchor+

Edge

1883 or 8883

MQTT(S) Port is required to communicate with the Anchor+

Edge

rtlscloud

1883 or 8883

MQTT(S) Port is required to communicate with the Edge

End user

*

rtlscloud

80 or 443

HTTP(S) Port is required to show the rtlscloud UI

Setup/Support

*

Anchor+

22

SSH to access the console to onboard and troubleshoot

*

Anchor+

443

HTTPS Port is required to onboard and troubleshoot

*

Edge

443

HTTPS Port is required to onboard and troubleshoot
